Harvia Legend 150 Stove Deluxe Kit SS
Harvia Legend 150, Chimney Kit, Protective bedding, Sheath, Water Heater, Stones
Model: LEGEND 150 DELUXE KIT SS
The Harvia Legend 150 Package is the ideal kit you will need for your dream sauna. This package contains: the Harvia Legend 150 Stove, Protective Bedding, Protective Sheath, 1500M Chimney Kit, 1000MM Chimney Extension, WK250LD Water Heater, WZ115120 Adapter Pipe, and Stones. Complementary to the Legend stove, an ultramodern blueprint of the water heater allows for safer sauna use. Feel confident and at ease knowing that the perfect placement of the tap is apart from the hot water tank resulting in zero hot water splashes. This package is available in the sleek modern look of stainless steel.
Description
The Harvia Legend 150 Package is the ideal kit you will need for your dream sauna. This package contains: the Harvia Legend 150 Stove, Protective Bedding, Protective Sheath, 1500M Chimney Kit, 1000MM Chimney Extension, WK250LD Water Heater, WZ115120 Adapter Pipe, and Stones. Complementary to the Legend stove, an ultramodern blueprint of the water heater allows for safer sauna use. Feel confident and at ease knowing that the perfect placement of the tap is apart from the hot water tank resulting in zero hot water splashes. This package is available in the sleek modern look of stainless steel.
Features
Harvia Legend 150 Stove
- Wood-Burning
- Heats two rooms
- Cleaner and efficient burning
- 16kW
- For sauna rooms from 212-459 cu. ft.
- Requires a minimum of 264lbs of stones ( 6 boxes-AC3020)
- Black steel frame
- Floor model
- Adjustable feet
- Designed, engineered and made in Finland
- Dimensions: 21"W (530mm) x 28"D (730mm) x 30"H (740mm)
- 2-year warranty (Consumer use)
Protective Bedding LG
- Aluminum-zinc coated steel
- Black
- Adjustable feet
- For wood-burning sauna heaters
- Helps protect floors
- Dimensions: 22" W (560mm), 25" D (636mm),2"-3" H (60-75mm)
- Can be installed on a sloping floor
- 2-year warranty
WL200 Protective Sheath
- Protective Sheath mounted can range from 1 to 3 as required
- Black color
- Reduces safety distance to combustible materials
- 2-Year warranty (Consumer use)
WHP1500 Chimney Kit
- Stainless Steel
- CE marking
- Mineral wool insulation material
- Mounts in vertical position
- Works with wood-heated stoves
- Works with smaller fireplaces
- Able to be easily extended
- Sootfire resistant
- Freeze thaw resistant
- Made in Finland
- 2-year warranty
WHP1000 Chimney Extension
- Innovative design
- Stainless Steel
- Prevents movement caused by temperature changes
- Can be installed indoors and outdoors
- Designed, engineered, and made in Finland
- Dimensions: 8.6" D (220mm) x 39.3" H (1000mm)
- 2-year warranty
WK250LD
- Heats water quickly
- New tap solution
- Tap can be fixed to wall or bench
- Stones covering front of tank
- Innovative design
- Dimensions: 14" W x 14" D x 35.8" H
WZ115120
- Stainless Steel
- CE Certification
- compatible with all Harvia wood-heated sauna wood-burning heaters (except Harvia 50) and the Harvia 10 iron wood-burning heater
- Dimensions: 7.9"H x 4.5" D x 4.5" W
Stones
- Olivine diabase sauna stones
- Split-Face
- Durable with high-heat capacity
- Stones range from 4" to 6" (10-15 cm)
Includes
Harvia Legend 150 Stove
- Sauna Stove
- Stove Door
- Ash box
- Installation and Operation Manual
- 2-year Warranty (Consumer use)
Protective Bedding LG
- Harvia Stove Protective Bedding
- Installation manual
- 2-year warranty
WL200 Protective Sheath
- Protective Sheath mounted can range from 1 to 3 as required
- Black color
- Reduces safety distance to combustible materials
- 2-Year warranty (Consumer use)
WHP1500 Chimney Kit
- Stainless Steel chimney
- Utility box
- Non-insulated smoke pipe
- Rain cap
- Rubber rain flange
- Installation set for rain flange
- Stainless steel lead-through flange for ceiling
- Lead-through insulation and protector
- Installation manual
- 2-year warranty
WHP1000 Chimney Extension
- 1000mm Stainless Steel chimney extension
- 2-year warranty
WP250LD
- Water Heater
- Installation & Operation Manual
- 2-Year Warranty
WZ115120
- Smoke Pipe
Stones
- 6 boxes of 44 lb box of 4" to 6" (10-15 cm)
Specifications
| Model | Legend 150 |
|---|---|
| Kilowatt Rating | 16kW |
| Primary Fuel | Wood |
| Maximum Firewood Length | 15" (39cm) |
| Diameter of Firewood | 3-5.9" (8-15cm) |
| Minimum Cubic Feet | 212 CF |
| Maximum Cubic Feet | 459 CF |
| Minimum Room Height | 69" (1750mm) |
| Flue Connection Location | Back, Top |
| Heater Weight | 135 lbs |
| Shipping Weight with Sauna Stones | 399 lbs |
| Width | 21" (530mm) |
| Depth | 28" (730mm) |
| Height | 30" (740mm) |
| Model | WL110 |
|---|---|
| Materiral | Steel |
| Weight | 26.5 lbs |
| Width | 22" (560mm) |
| Depth | 25" (636mm) |
| Height | 2"-3" (60-75mm) |
| Model | WL200 |
|---|---|
| Weight | 15 lbs |
| Width | 20" (520mm) |
| Depth | 5" (125mm) |
| Height | 39" (1000mm) |
| Model | WHP1500 |
|---|---|
| Material | Stainless Steel |
| Non-vertical installations | Not Allowed |
| Product Height | 59" (1500mm) |
| Product Diameter | 8-5/8" (220mm) |
| Net Weight | 25 lbs |
| Model | WHP1000 |
|---|---|
| Material | Stainless Steel |
| Flexural Strength- tensile strength | 16.4 ft (5m) |
| Non-vertical installations | Not Allowed |
| Wind Load | 6.5 ft (2m) above last support |
| Maximum spacing of lateral supports | 9.8 ft (3m) |
| Weight | 14.8 lbs |
| Diameter | 8.6" (220mm) |
| Height | 39.3" (1000mm) |
| Model | WP250LD |
|---|---|
| Construction | Steel |
| Color | Black |
| Stone Size | 5-10 cm |
| Net Weight | 24 lbs |
| Width | 14" |
| Depth | 14" |
| Height | 35.8" |
| Model | WZ11520 |
|---|---|
| Construction | Stainless Steel |
| Width | 4.5" |
| Depth | 4.5" |
| Height | 7.9" |
Technical
Harvia Legend 150 Manual
Harvia 150 Datasheet
Harvia Legend Declaration of Performance
Harvia Legend Safety Distances
Harvia Legend Spare Parts
Protective Bedding Manual
Protective Sheath Manual
Chimney Kit Manual
Chimney Extension Manual
Harvia WP250LD Manual
