Delta Auto Drain
Voltage Phase:208V
Quantity:
Auto Drain for 5GE-SMP Series
Model: Delta Auto Drain
SKU: 5GA-ADD-208
The Delta Auto Drain is an optional add-on to the 5GE-SMP Series Steam Generator that automatically purges water from the system after each steam shower.
Description
The Delta Auto Drain is an optional add-on to the 5GE-SMP Series Steam Generator that automatically purges water from the system after each steam shower.
Features
- Automatically purges the system by gravity once water in the generator cools
- Connects to a factory installed auto drain terminal block located inside the generator cabinet
- Valve body with 1/2" NPT brass female connection
- Normally Closed Valve (N.C.)
- Designed for use with 208V and 240V 5GE-SMP Series Steam Generators (voltage should match the voltage of your generator)
Includes
- Auto Drain
Specifications
| Model | Auto Drain |
|---|---|
| Voltage | 208 or 240 |
| Width | 2.38" (60 mm) |
| Depth | 3.5" (89 mm) |
| Height | 4.25" (108 mm) |
| Inlet & Outlet Connection | 1/2" NPT Brass Female Thread |
| Prop 65 WARNING | Lead |
Technical
Installation and Operation Manual
Delta-5GA-ADD-Auto-Drain-IOM.pdf298.42 KB
Technical Specifications
