Amerec I60
Quantity:
60-Minute Timer Control, AI Series
Model: I60
SKU: 9226-10
Optional, and for use with all Amerec AI boilers the user activated, I60 60-Minute Electronic Timer mounts near the steam room for steam on/off 60-minute timer operation.
Description
The user activated, I60 electric bath timer mounts near the steam room for steam on/off operation. Designed to control steam flow in steam rooms with intermittent use, this optional control offers 60 minutes of automatic bath time. One per steam room.
Features
- 60-minute countdown timer switch
- Mode indicator light
- 5V DC operation
Includes
- 3-lead, 25’ control cable
- I60 timer, (4½”x2½”)
- Fasteners
- Decorative wall plate
- Installation and operation manual
Specifications
| Model | I60 |
|---|---|
| Shipping Weight | 2 lbs |
| DC Voltage | 5V DC |
| Control "Rough In" Cut Out | 2-1/8" x 3-3/4" |
| Control Sensor Cable | 25', 3 Conductor, 22 AWG, Shielded Cable |
| Generator Control Connection | 3 Position Terminal Block |
| Generator Control Cable | 25', 3 Conductor, 22 AWG, Shielded Cable |
| Width | 2-3/4" |
| Depth | 1" |
| Height | 4-1/2" |
Technical
Installation and Operation Manual
I60 IOM.pdf373.96 KB
